Name: BL1.5 Black Stone Dosing Pump 1.5lph 13 bar
SKU: BL1.5-2
Price: 11235.00 THB
Availability: InStock

Blackstone pumps are completely sealed during assembly and offer IP65 protection against splashes and spills providing excellent protection even in hostile environments. The fiber-reinforced polypropylene housing stands up to aggressive chemicals while offering superior strength under tough industrial conditions.

Order Information:
BL 1.5-2 1.5 LPH flow rate

Product Manuals

Manual: Download

unbenannt51dc0a27610fa

Specification :

Max Output		see above chart
Rated Pressure	BL 20	0.5 bar (7.4 psi)
	BL 15	1 bar (14.5 psi)
	BL 10	3 bar (43.5 psi)
	BL 7	3 bar (43.5 psi)
	BL 5	7 bar (101.5 psi)
	BL 3	8 bar (116 psi)
	BL 1.5	13 bar (188.5 psi)
Dosing Frequency		120 strokes/min
Pump Casing		fiber-reinforced polypropylene
Materials		pumphead in PVDF, diaphragm in PTFE, glass ball valves and O-rings in FPM/FKM, polyethylene 5 x 8 mm tubing
Self-priming		max height: 1.5 m (5 feet)
Power Supply		110/115 VAC or 220/240 VAC, 50/60Hz
Max Power Consumption		approximately 200 W
Protection		IP65
Environment		0 to 50°C (32 to 122°F); RH max 95% non-condensing
Dimensions		194 x 165 x 121 mm (7.6 x 6.5 x 4.8’’)
Weight		approx. 3 kg (6.6 lb.)
