COD Test Tube Heater with 25Vials – HI839800-02

COD Test Tube Heater with 25Vials – HI839800-02

HI839800 is a robust 25 vial capacity thermo-reactor for COD determination of industrial wastewater.
The reactor has three stored and three programmable (custom) temperature programs.

The stored programs support analysis methods at:
    • 170°C (all COD methods)
    • 150°C (all COD methods, Iron Total, Phosphorus Acid Hydrolyzable, Phosphorus Total methods)
    • 105°C (Chromium and Nitrogen Total methods)
Main Features
    • Up to 180 minutes built-in countdown timer
    • Indicator light for POWER (on), HOT (surface), HEATING (in progress)
    • Reactor block temperature continuously evaluated and displayed
    • Reference temperature probe well

Features

Predefined Temperature Settings – The test tube heater features three predefined temperature profiles at 170ºC 150ºC and 105ºC that can be selected at the press of a button.

Temperature Alerts – The HI839800 alerts users in the event that the temperature of the heating block is either above or below the set temperature. A timer icon reminds users to wait until the heating block has cooled or warmed up before inserting their samples.

Built-in Timer – A built-in countdown timer of up to 180 minutes allows users to easily set the required digestion time by simply pressing the up and down arrows. Once a time has been set and the heating element is stable, a press of the START button begins the digestion procedure.

Status Indicator Lights – Three LED lights are featured on the HI839800. A green LED indicates the heater has been turned on; a yellow LED indicates when the heater is actively heating up to a set temperature; a red LED indicates when the heater goes above 50ºC, reminding the user that the aluminum element is hot.

Overheating Prevention – The HI839800 contains a thermal fuse that prevents overheating. Should overheating occur, the heater automatically shuts down and all LED indicator lights turn off.

Reference Temperature Well – In addition to the 25 vial capacity of the aluminum heating block, a small well is available for a temperature probe for users that wish to verify their heating block.

Two Operating Modes – The HI839800 features two operating modes: idle and heating. Idle mode is the default mode in which the heater measures and displays the current temperature, target temperature, set reaction time, and an “idle” tag. Heating mode is activated when users press the START button; it starts when actively heating and continues during the countdown timer.

Continuous LCD Display – The block temperature is continuously displayed on the easy to read LCD display, even when there is no active temperature program running. All relevant information in addition to temperature are easily visible during idle and heating mode.

Error Messages – Messages on display alerting to problems including high or low temperature, hot surface, or heating system malfunction.

Manual: Download

Specification :

Temperature of Reaction		30.0 to 170.0°C (86 to 338°F)
Temperature Stability		±0.5°C
Temperature Range		-10°C to 160°C (14°F to 320°F)
Accuracy		±2°C
Capacity		25 vials; Ø 16 mm × 100 mm Reference temperature probe well
Warm-up Time		10-15 minutes, depending on selected temperature
Operating Mode		timed (0 to 180 minutes) or infinity mode
Block		aluminum
Environment		5 to 50°C (41 to 122°F)
Power Supply (fuse protected)		HI 839800-02: 230 VAC; 50 Hz; 250 W
Dimensions		190 x 300 x 95 mm
Weight		approximately 4.8 kg
